Factory For Screw Compressor Hose - Oil Suction & Discharge Hose OSD300 – Sinopulse Detail:

Construction:

Inner Tube:Black Extruded NBR  synthetic  rubber.

Reinforcement:  High tensile textile cord  with steel wire helix spiraled.

Cover:High tensile synthetic abrasion and weather resistant rubber, black wrapped surface.

Working Pressure:Constant Pressure 20 Bar /300 psi

Temperature Range:-20℃~+80℃ (-4°F~176°F)

Application:Mainly used to suction and discharge the petroleum, diesel,  gasoline and hydraulic oil based fluid for varies machines and equipment.

Feature:

√Mandrel extrusion technology

√Free OEM Color & Brand Service

√Packing as customer request

Specification:

Part No. ID  OD Working Pressure Burst Pressure Layer
inch mm mm Bar psi Bar psi ply
OSD300-12 3/4″ 19.1  30.8  20 300 60 900 2
OSD300-16 1″ 25.4  36.8  20 300 60 900 2
OSD300-20 1-1/4″ 31.8  46.4  20 300 60 900 4
OSD300-24 1-1/2″ 38.2  53.0  20 300 60 900 4
OSD300-28 1-3/4″ 45.0  60.8  20 300 60 900 4
OSD300-32 2″ 50.8  66.8  20 300 60 900 4
OSD300-40 2-1/2″ 64.0  81.2  20 300 60 900 4
OSD300-48 3″ 76.0  93.2  20 300 60 900 4
OSD300-56 3-1/2″ 89.0  107.4  20 300 60 900 4
OSD300-64 4″ 102.0  120.4  20 300 60 900 4
OSD300-72 5″ 127.0  149.8  20 300 60 900 6
OSD300-80 6″ 152.0  174.8  20 300 60 900 6
OSD300-128 8″ 203.0  231.2  20 300 60 900 6
OSD300-160 10“ 254.0  286.4  20 300 60 900 6
OSD300-192 12” 304.8  337.4  20 300 60 900 6

Product detail pictures:

Factory For Screw Compressor Hose -
 Oil Suction & Discharge Hose OSD300 – Sinopulse detail pictures

Factory For Screw Compressor Hose -
 Oil Suction & Discharge Hose OSD300 – Sinopulse detail pictures
